High Speed Rc Servo Robot Arm Gripper Mechanical Claws Servo Corona DS238MG

Basic Information
Place of Origin: Jiangsu, China
Brand Name: Corona
Certification: ISO9001 CE ROHS
Model Number: DS238MG
Minimum Order Quantity: 2pieces
Price: $9.15/pieces 1-10 pieces
Packaging Details: box
Delivery Time: 5-8 working days
Payment Terms: L/C, D/A, D/P, T/T
Supply Ability: 3000 pieces per day
Detail Information
Type: Mini Servo Size: 29x13x30mm(1.14"x0.51"x1.18")
Weight: 22g(0.77OZ) Operating Voltage: 4.8V / 6.0V
Operating Current: 300mA / 400mA Stall Torque: 4kg.cm / 4.6kg.cm
Dead Band: ≤3uSec Potentiometer: 3 Slider/Indirect Drive
Ball Bearing: MR106 Gear: Metal
Connector Wire Length: 215mm Power: Standard
Material: Standard Plastic Type: Standard
Scale: Standard Radio Control Style: RC Hobby
High Light:

rc servo robot arm

,

high speed rc servo

,

high speed servo rc


Product Description

Corona DS238MG metal gear robot gripper robot mechanical claws servo

Much like the 525130, this 25T spline servo horn is a round disk that can be used to fasten Actobotics components which possess the 0.77” hub pattern (and hence, the ½” hole in the center). This lightweight model is thinned out and does not contain the counterbored holes to minimize rotating mass and additional bulk.

High Speed Rc Servo Robot Arm Gripper Mechanical Claws Servo Corona DS238MG 0



Item No DS238MG
Size 29x13x30mm(1.14"x0.51"x1.18")
Weight 22g(0.77OZ)
Operating Voltage 4.8V / 6.0V
Operating Current 300mA / 400mA
Operateing speed 0.15sec.60º/ 0.14sec.60º
Stall torque 4kg.cm / 4.6kg.cm
Dead band ≤3uSec
Operating Travel 40º/one side pulse traveling 400us
Potentiometer 3 slider/Indirect Drive
Ball bearing MR106
Gear Metal
Connector wire length 215mm
Operating Temperature Range -20 ℃ to +60℃

    These iconic servos have been applied by plenty of groups, like hobbyists, students, engineers,dreamers,etc. Low cost and reliable servos are available to you. Please feel free to contact us if you have bulk orders or custom and even OEM / ODM.

High Speed Rc Servo Robot Arm Gripper Mechanical Claws Servo Corona DS238MG 1

Servo Applications:
1. Electric lock (anti-heft door lock servo)

2. Smart lamp Switch Servo

3. Washing machine safety mechanism servo

4. Water/gas valve control Servo
5. Luggage case lock servo

6. Camera gimbal control servo
7. UAV heavy duty servo

7. Servo Release Servo Drop

9. Safety lock servo
10. Automatic Perfume and liquids Sprayer Servo

11. Smart bike gear change servo
12. Electric car mirror servo

13. Car seat adjustment servo
14. Robot arm servo

15. Medical equipment servo

16. Curtain Servo

17. Robot servo

18. Wheel servo

19. Car window winding servo

High Speed Rc Servo Robot Arm Gripper Mechanical Claws Servo Corona DS238MG 2



Other Product

High Speed Rc Servo Robot Arm Gripper Mechanical Claws Servo Corona DS238MG 3

High Speed Rc Servo Robot Arm Gripper Mechanical Claws Servo Corona DS238MG 4

Company Information

High Speed Rc Servo Robot Arm Gripper Mechanical Claws Servo Corona DS238MG 5

Corona Electronics and Technology CO.,LTD is one of the leading professional receiver and servo manufacturers in China.Corona boasts the lightest,smalllest and most reliable receivers and servo with the greatest range in the RC world.We specialize in designing and manufacturing Servos and 2.4GHz combos for Futaba and JR radios . As an export-oriented company , Corona has excellent international distribution channels and our products are sold to more than 40 countries around the world.Corona is based in Wu Xi City which is very close to Shanghai.If you come to China,you are very welcome to visit our office and our factory.
Our motto at Corona is Technological innovation & striving for perfection.We will continue to grow and strive to produce original, innovatively engineered,top quality products to share with the RC World.

High Speed Rc Servo Robot Arm Gripper Mechanical Claws Servo Corona DS238MG 6

High Speed Rc Servo Robot Arm Gripper Mechanical Claws Servo Corona DS238MG 7

Packaging & Shipping

 High Speed Rc Servo Robot Arm Gripper Mechanical Claws Servo Corona DS238MG 8

FAQ

1. Why choose us?
We are one of the leading professional receiver and servos manufacturers in china and we have been in this industry for almost 14 years. Most of all, we have own factory. The product cost is competitive.
2.What is your terms of payment?

For payment, we accept payment by T/T, paypal, Alibaba trade assurance.If you want any other payment term, please let us know before you place an order.
3. Which shipping service is better?

For shipping ways, there are many shipping ways that you can choose For example, sea shipping, China post, China airmail, EMS. DHL, Fedex, UPS, and TNT ect.
4. How about your delivery time?

Most of our products are in stock, so we can have your goods shipped within 3 days after payment.
5. What is your terms of delivery?

EXW,FOB,CFR,CIF,DDU.
6.Do you test all your goods before delivery?
Yes,we have 100% test before deliver.
7. What is your sample policy?
We can supply the sample,but you pay the sample cost and The shipping fee.
8. Can you produce according to the samples?
Yes, we can produce with your samples or technical drawings.
