| Place of Origin: | Jiangsu, China |
|---|---|
| Brand Name: | Corona |
| Certification: | IS9001 CE ROHS |
| Model Number: | DS939MG II |
| Minimum Order Quantity: | 2 pieces |
| Price: | $5.75/pieces -$7.46 pieces |
| Packaging Details: | one pieces per color box packing |
| Delivery Time: | 7 working days |
| Payment Terms: | T/T, Western Union,Paypal . Alibaba Trade Assurance |
| Supply Ability: | 30000 pcs/per Month |
| Type: | Mini Servo | Gender: | Unisex |
|---|---|---|---|
| Age Range: | 14 Years & Up | Size: | 22.5X11.5X24.6mm(0.88"x0.45"x0.96") |
| Weight: | 15.1g | Operating Voltage: | 4.8V / 6V |
| Operating Current: | 200mA / 240mA | Stall Torque: | 3.6kg.cm /4.1kg.cm |
| Dead Band: | ≤2uSec | Potentiometer: | 2 Slider/direct Drive |
| Ball Bearing: | MR85 | Gear: | Metal |
| Connector Wire Length: | 215mm | ||
| High Light: | corona ds939mg digital servo,digital mini servo,mini servo motor 9g |
||
Corona DS939MG II Mini Size 9g 4.1kg 0.14sec Full Metal Gear Digital Servo For Rc Robot Helicopter
DS939MGII is the updating one of DS939MG. The differences between DS939MG and DS939MGII are the torque and gears. The torque of the servo DS939MG is 2.7kg.cm at 6.0v and the torque of DS939MGII is 4.1kg.cm at 6.0v. DS939MG is composed of one plastic gear and four metal gears, but DS939MGII all the gears are metal, so the lifetime of the servo DS939MGII is stronger than the one DS939MG. DS939MGII is more suitable for industrial use.
| Item No | DS939MG II |
| Size | 22.5X11.5X24.6mm(0.88"x0.45"x0.96") |
| Weight | 15.1g |
| Operating Voltage | 4.8V / 6.0V |
| Operating Current | 200mA / 240mA |
| Operateing speed | 0.15sec.60º/ 0.14sec.60º |
| Stall torque | 3.6kg.cm /4.1kg.cm |
| Dead band | ≤2uSec |
| Operating Travel | 40º/one side pulse traveling 400us |
| Potentiometer | 2 slider/Direct Drive |
| Ball bearing | MR85 |
| Gear | Metal |
| Connector wire | 215mm |
| Operating Temperature Range | -20℃~+60℃ |
